• Self-protection system

1. Touch buttons ensure excellent operability.

2、It has a dangerous automatic shutdown function, which can shut down the unit within 0.1 seconds upon detecting abnormal parameters.

3、232/485 interfaces are reserved for seamless connection with computers (subject to the support of relevant devices).

4、The large-screen LCD display function makes all data at a glance. The backlight design ensures readability.

5、With an imported microprocessor and a professionally designed program, it continuously monitors the conditions of diesel engines and generators for 24 hours. It automatically monitors technical parameters such as diesel engine speed, oil pressure, water temperature, and voltage, providing all-around protection for the unit.

• Self-start system

Function Introduction

-It incorporates all the functions of the self-protection system.

-It automatically monitors the utility power. When the utility power is lost, it automatically starts the generator set and checks whether the generator set has started successfully.

-Once the utility power signal is detected, it automatically reduces the speed of the generator set and shuts it down.

-If the start fails three times, it will automatically alarm, with clear indication for fault protection items.

• ATS Fully Automatic Control System

ATS Fully Automatic Control System Function Introduction

-Incorporates all the functions of the self-start system.

-Automatically monitors the utility power. After starting the generator set, it independently switches on the load.

-Professionally equipped with an ATS transfer system, ensuring safe, convenient, and efficient power delivery.

-Once the utility power signal is detected, it independently cuts off the power supply to the load, and automatically reduces the speed of the generator set and shuts it down.

-An unattended, round-the-clock generator set control system.

• Generator Paralleling System

Generator Paralleling System Features

-Applicable for both single-unit operation and multi-generator paralleling. There is no distinction between master and slave units.

-Primarily designed for fully automatic operation, yet also suitable for manual operation.

-Provides electrical parameters such as line voltage, line current, output active power, power factor, and frequency for each generator.

-Displays operating parameters like lubricating oil pressure, coolant temperature, rotational speed, and battery voltage of each engine. Offers sensors for low oil pressure, high water temperature,overspeed,underspeed, reverse power,undervoltage, overcurrent, output short-circuit, as well as oil pressure, water temperature, and rotational speed.

-Provides protection against open-circuit and short-circuit.

-The system can automatically achieve paralleling with automatic frequency tracking, automatic synchronizing, and even distribution of active load.
